051521-0023 by itt cannon
Image is representational - see mfr. specs

051521-0023

ITT CANNON

Conn D-Subminiature SKT 15 POS Solder ST Thru-Hole 15 Terminal 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

051521-0023 is a high-reliability D-Sub socket connector from the D'M series, designed for robust electrical interconnection in demanding environments. It features a 15-contact arrangement with size 20 contacts, supporting wire gauges from AWG 20-28 and a maximum current rating of 7.5 A. The connector offers excellent electrical performance with a dielectric withstanding voltage of 1000 VAC at sea level and contact resistance of 7.5 milliohm maximum. Constructed with a steel shell featuring yellow chromate over zinc finish and gold over nickel plated copper alloy contacts, it operates reliably across a wide temperature range of -55°C to +150°C. This straight PCB-mount connector is ideal for applications requiring high mating cycle durability (500 cycles) and corrosion resistance with 48-hour salt spray test compliance.

Search Keywords: 0515210023

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
051521-0023
Alias/AKA:
DAMM-15S-Z
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Socket
Termination Method:
Solder
Shell Size:
A
Number of Contacts:
15
Contact Plating:
Gold over Nickel
Operating Temperature:
-55°/+150 °

IN STOCK: 39

Can Ship immediately

On Order: 150   can ship 7/16/26

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$60.06
5
$41.97
10
$39.25
25
$38.02
50
$36.45
100
$36.09
250 +
$34.22
Log in for special pricing Click for Quote Price Match Request
