DBMM-25S-Z by itt cannon
Image is representational - see mfr. specs

DBMM-25S-Z

ITT CANNON

Conn D-Subminiature SKT 25 POS Solder ST Thru-Hole 25 Terminal 1 Port ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

DBMM-25S-Z is a D Subminiature connector from ITT Cannon's military/high reliability product line, featuring a DB shell size with a 25-contact layout. This connector is designed for straight PC tail mounting with solder termination and is available in various pin diameter and length configurations. The DB shell size provides dimensions of A: 53.04 mm (2.088 in), B: 38.96 mm (1.534 in), and C: 47.04 mm (1.852 in). Commonly used in commercial/industrial and military/aerospace applications, this connector offers reliable interconnect solutions for equipment ranging from office systems to satellites.

Search Keywords: DBMM25SZ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
ITT CANNON
Part No:
DBMM-25S-Z
Alias/AKA:
051523-0036
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
Socket
Termination Method:
Solder
Shell Size:
B
Number of Contacts:
25
Contact Plating:
Gold over Nickel
Operating Temperature:
-55°/+150 °

IN STOCK: 0

On Order: 100   can ship 7/17/26

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$97.84
5
$81.21
10
$70.60
25
$61.54
50
$59.61
100
$59.01
250 +
$57.61
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
