142-0701-501 by johnson / cinch connectivity solutions
Image is representational - see mfr. specs

142-0701-501

Johnson / Cinch Connectivity Solutions

SMA Jack Assembly, Right Angle PCB Mount Bulkhead

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 142-0701-501 is a RF/Coaxial Connector, SMA right angle bulkhead jack receptacle with gold plated brass body, gold plated contact, right angle printed circuit board style, solder termination type and bulkhead mount.

Search Keywords: 1420701501

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Johnson / Cinch Connectivity Solutions
Part No:
142-0701-501
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Bag
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 18 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
19.69 mm

IN STOCK: 2,909

Ships today, if you order in

On Order: 2,500   can ship 8/3/26

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
25
$6.29
50
$5.92
100
$5.87
250
$5.65
500
$5.63
1,000
$5.60
2,500 +
$5.57
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
