7101P3YCQE

Miniature Toggle Switch - SP (On-None-On) - 5A@120VAC/2A@250VAC - .450" Flatted Anti-rotation Actuator - PCB Pin - 1/4-40 Bushing - Epoxy Seal ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

Introducing the C&K COMPONENTS part 7101P3YCQE, a powerful yet compact Miniature Toggle Switch designed for hassle-free PCB mounting applications. This switch features a reliable SP (On-None-On) configuration, capable of handling 5A at 120VAC and 2A at 250VAC for efficient performance. The .450" Flatted Anti-rotation Actuator ensures precise control, while the 1/4-40 Bushing provides a secure fit. With a durable Epoxy Seal for added protection, this toggle switch is built to last.

Search Keywords: 7101P3YCQE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse / C&K
Part No:
7101P3YCQE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
OTHER
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
5@120VAC 28VDC A
Actuator Style:
Flat Lever
Mounting:
PC Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
PC Pins
Dimension:
12.7 x 6.86 x 30.76 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 129

Ships today, if you order in

On Order: 100   can ship 11/20/26

Minimum Order Quantity: 5

Factory Lead-Time 31 Weeks

Price (USD)

Qty
Unit Price
5
$13.72
25
$12.37
50
$11.71
100
$10.89
300
$10.43
500
$10.09
1,000 +
$9.63
