7201SYCBE by littelfuse / c-k
Image is representational - see manufacturer specifications
Littelfuse / C&K Authorized Distributor

7201SYCBE

Miniature Toggle Switch - DP (On-None-On) - 0.4VA@20V - .420" Actuator - PCB Pin - 1/4-40 Bushing - Epoxy Seal ...

View Datasheet Ask the Datasheet
RoHS Compliant
OTHER Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 7201SYCBE is a miniature DPDT toggle switch from the C&K 7000 Series designed for compact switching applications requiring dual independent circuits. It features a contact rating of 5 amps at 120 V AC or 28 V DC, and 2 amps at 250 V AC, with contact resistance below 10 mO typical at 2–4 V DC and 100 mA. The switch provides 1000 Vrms minimum dielectric strength at sea level and 10? O minimum insulation resistance, with an electrical life of 40,000 make-and-break cycles at full load. Operating temperature range is -30 °C to +85 °C, and the switch features an epoxy seal with solder lug termination (Z option). This configuration is ideal for control panels, instrumentation, and industrial equipment where reliable dual-circuit switching in a compact form factor is required.

Search Keywords: 7201SYCBE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse / C&K
Part No:
7201SYCBE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
OTHER
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
0.4@20VAC 20VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
PC Pins
Dimension:
12.7 x 11.43 x 30 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 31

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$19.52
25
$13.64
50
$12.75
100
$12.15
300
$11.33
500
$11.13
1,000 +
$11.10
