ATF22V10C-15PU by microchip technology

ATF22V10C-15PU

Microchip Technology

SPLD ATF22V10C Family - 15 ns - 5V - 10 I/O's - 83.3 MHz - 115 mA - PDIP - 24 Pins. ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ATF16V8BQL-15PU is a high-performance CMOS Electrically-Erasable Programmable Logic Device (EE PLD) that utilizes the Atmel proven electrically-erasable flash memory technology. All speed ranges are specified over the full 5.0V ±10% range for industrial temperature range. The ATF16V8BQL provides edge-sensing low-power PLD solution with low standby power consumption (5mA typical). The ATF16V8BQL powers down automatically to the low-power mode through the Input Transition Detection (ITD) circuitry when the device is idle. The ATF16V8B(QL) incorporate a super set of the generic architectures, which allows direct replacement of the 16R8 family and most 20-pin combinatorial PLDs. Eight outputs are each allocated eight product terms. Three different modes of operation, configured automatically with software, allow highly complex logic functions to be realized.

Search Keywords: ATF22V10C15PU

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
ATF22V10C-15PU
RoHS:
Yes
HTS:
8542310055
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
15
Package Type:
TUBE
Family Name:
ATF22V10C
Maximum Operating Supply Voltage:
5.5 V
Family:
ATF22V10C
Maximum Operating Current:
N/A
Fabrication Technology:
N/A
In-System Programmability:
No
Dimension:
32.3(Max) x 7.11(Max) x 5.33(Max) - 0.38(Min) mm
Maximum Internal Frequency:
83.3 MHz
Device System Gates:
500
Maximum Number of User I/Os:
10

IN STOCK: 2,400

Ships today, if you order in

Minimum Order: 15

Multiple: 15

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
15
$2.431
60
$2.297
255
$2.142
510
$2.091
1,005
$2.009
2,505
$1.978
5,010
$1.947
7,500 +
$1.916
Suppliers Standard Package
