NC3FAH2 by neutrik
Image is representational - see mfr. specs

NC3FAH2

NEUTRIK

A Series - 3 pole female XLR receptacle, grounding: separate ground contact to mating connector shell and front panel - horizontal PCB mount The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest siz ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NC3FAH2 is 3 pole female XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, horizontal PCB mount The NC3FAH2 has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm between centres). New designed tulip type contacts with hard gold plating and polished contact areas. UL recognized component.

Product Highlights:

  • Smallest XLR receptacles, highest packing density
  • Plastic housing, steel latch lock
  • Tulip type female contact
  • Polished contact areas and hard gold plating
  • Housing flammability UL94 V-0

Search Keywords: NC3FAH2

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NC3FAH2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040.00
COO:
LI
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
Gold
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

IN STOCK: 1,791

Can Ship immediately

Manufacturer Stock: 8,000   can ship 5/4/26

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 3 Weeks can ship 5/14/26

Price (USD)

Qty
Unit Price
100
$3.75
300
$3.52
500
$3.40
1,000
$3.25
2,500
$3.07
5,000
$2.93
7,500
$2.84
10,000 +
$2.78
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
