NC3MAV by neutrik
Image is representational - see manufacturer specifications
NEUTRIK Authorized Distributor

NC3MAV

A Series - 3 pole male XLR receptacle - grounding: separate ground contact to mating connector shell and front panel - vertical PCB mount The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size a ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NC3MAV is 3 pole male XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, vertical PCB mount The NC3MAV has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23 mm between centres). Hard gold plated contacts with polished contact areas. UL recognized component.

Search Keywords: NC3MAV

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NC3MAV
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
LI
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
M
Body Orientation:
Straight
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

IN STOCK: 98

Ships today, if you order in

Buy all 98 in-stock or the regular minimum order quantity of 100

On Order: 1,598   can ship 9/30/26

Stock lot only: 98

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$1.620
100
$1.473
300
$1.463
500
$1.432
1,000
$1.421
2,500
$1.370
5,000
$1.360
7,500
$1.349
10,000 +
$1.339
Supplier's Standard Package
