NC5MD-L-1 by neutrik
Image is representational - see mfr. specs

NC5MD-L-1

NEUTRIK

DL Series - 5 pole male receptacle - solder cups - Nickel housing, silver contacts Universal D-size metal body XLR panel mount series. UL recognized component. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NC5MD-L-1 is 5 pole male receptacle, solder cups, Nickel housing, silver contacts The NC5MD-L-1 has rated voltage of < 50 V and rated current per contact of 7,5 A and dielectric strength of 1,5 kVdc . Universal D-size metal body XLR panel mount series. UL recognized component.

Product Highlights:

  • Robust "D" metal shell
  • Standardized D sized 24 mm panel cutout
  • Solder cups on 3 - 7 pole version

Search Keywords: NC5MDL1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NC5MD-L-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040.00
COO:
HU
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
M
Body Orientation:
Straight
Mounting:
Panel Mount
Housing Material:
Zinc Die Cast
Number of Contacts:
5
Contact Plating:
Silver over Nickel
Termination Method:
Solder Cup
Operating Temperature:
-30 to 80 °C

IN STOCK: 67

Ships today, if you order in

Manufacturer Stock: 700   can ship 5/4/26

Minimum Order Quantity: 5

Factory Lead-Time 3 Weeks can ship 5/14/26

Price (USD)

Qty
Unit Price
5
$21.40
25
$9.45
50
$9.35
100
$8.31
300
$8.19
500
$7.85
1,000 +
$7.78
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
