B3F-3150 by omron electronics

B3F-3150

Omron Electronics

Switch Tactile N.O. SPST Projected Plunger PC Pins 0.05A 24VDC 0.98N Thru-Hole Bag ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Omron B3F series are tactile switches. These switches are available in 6mm × 6mm, 12mm × 12mm sizes with different models such as standard, side operated, long durability, high force and high reliability gold plated etc. The gold plated models have increased contact reliability, resistance to corrosive gas and insulation failure prevention for ion migration in harsh environments. Extended mechanical/electrical durability Taped radial type, vertical type and high force types are available Flat type and projected type plunger DIP terminals Operating force is 0.98N, 1.27N, 1.47N, 1.76N, 2.55N, 4.9N based on ordering SPST-NO contact configuration Maximum switching capacity of 50mA at 24VDC Type B32 key tops are available only for projected plunger models Applications Industrial, Power Management, Automation & Process Control

Search Keywords: B3F3150

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
B3F-3150
RoHS:
Yes
HTS:
8536509065
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Dimension:
8.7 x 10.15 x 7.4 mm
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Projected Plunger
Operating Force:
0.98 N
Contact Rating @ Voltage:
0.05@24VDC A
Illumination Type:
N/R
Body Orientation:
Right Angle
Termination Style:
PC Pins
Seal Location:
N/A

IN STOCK: 6,211

Can Ship immediately

Minimum Order: 100

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
100
$0.4514
500
$0.3470
3,000
$0.3417
5,000
$0.3399
8,000
$0.3382
25,000
$0.3366
50,000 +
$0.3348
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
