B3S-1002 by omron electronics

B3S-1002

Omron Electronics

Switch Tactile N.O. SPST Round Button Gull Wing 0.05A 24VDC 500000Cycles 2.26N SMD Bag ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The B3S series from Omron are surface mount tactile switches for high contact reliability. SPST-NO contact configuration Switching capacity of 1 to 50mA at 5VDC to 24VDC Maximum contact resistance of 100mohm Minimum insulation resistance of 100Mohm Sealed construction conforming to IP67 Surface mounting terminals for high density mounting Ground terminal available to protect against static electricity Operating force of 160gf (general purpose) and 230gf (high force) 6mm x 6mm size Applications Industrial, Power Management, Automation & Process Control

Search Keywords: B3S1002

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
B3S-1002
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1500
Dimension:
6.6 x 9 x 4.3 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Round Button
Operating Force:
2.26 N
Contact Rating @ Voltage:
0.05@24VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
Gull Wing
Seal:
N/A
Seal Location:
N/A

IN STOCK: 3,167

Ships today, if you order in

Minimum Order: 50

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
50
$0.5150
500
$0.4529
1,500
$0.4234
3,000
$0.4049
6,000
$0.3614
10,500
$0.3474
15,000
$0.3386
25,500 +
$0.3253
Suppliers Standard Package
