1727010
PCB terminal block - nominal current: 13.5 A - rated voltage (III/2): 200 V - nominal cross section: 1.5 mm² - pitch: 3.81 mm - number of positions: 2 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm ...
DESCRIPTION
The PHOENIX CONTACT part 1727010 is a PCB terminal block designed for efficient and reliable connections in electronic circuits. With a nominal current rating of 13.5 A and a rated voltage of 200 V (III/2), it is capable of handling high-power applications. The terminal block has a nominal cross section of 1.5 mm² and a pitch of 3.81 mm, allowing for easy and secure connection of wires. It features a screw connection with tension sleeve, ensuring a strong and stable connection. The terminal block is designed for wave soldering mounting and has a conductor/PCB connection direction of 0 °. The color of the terminal block is green, making it easily distinguishable in a circuit. It has a pin layout of linear pinning and solder pin with a length of 3.5 mm.
Search Keywords: 1727010
SPECIFICATIONS
IN STOCK: 2,444
Ships today, if you order in
Minimum Order Quantity: 250
Multiple: 250
Factory Lead-Time 5 Weeks
Price (USD)
Tools/3D Models
Product Guides
Datasheet
Product Changes
PCN - 01-Jan-2019 - DATA SHEETS AND PACKAGING LABELS WILL BE UPDATED
