G5Q-1A4-DC24 by omron electronics
Image is representational - see mfr. specs

G5Q-1A4-DC24

Omron Electronics

Power Relay 24VDC 5DC/10AAC SPST-NO (20.3mm 10.3mm 16.2mm) THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G5Q-1A4-DC24 is a fully sealed Miniature Power Relay with silver alloy cadmium-free contacts, SPST-NO contact configuration and through-hole PCB straight termination. The G5Q series general-purpose PCB power relay is ideal for output applications of control equipment. Excellent switching performance for a variety of loads Class F coil insulation 200mW Low coil power consumption 4000VAC Dielectric strength (AC for 1 minute) 8000V Impulse withstand voltage 100mΩ Maximum contact resistance 1000MΩ Minimum insulation resistance Applications Industrial

Search Keywords: G5Q1A4DC24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G5Q-1A4-DC24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 105 °C
Coil Resistance:
2.88 KOhm

IN STOCK: 14,972

Can Ship immediately

On Order: 19,000   can ship 9/23/26
On Order: 16,000   can ship 3/31/27

Minimum Order Quantity: 25

Factory Lead-Time 53 Weeks

Price (USD)

Qty
Unit Price
25
$1.42
250
$1.27
500
$1.22
1,000 +
$1.17
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
