G6K-2F-Y-DC5 by omron electronics

G6K-2F-Y-DC5

Omron Electronics

Signal Relay 5VDC 1A DPDT(10x7.8x5.2)mm SMD ...

Datasheet
RoHS Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G6K2FYDC5 is a highly insulated Single-side Stable Relay with silver alloy bifurcated crossbar contact, DPDT contact configuration and surface mounting terminals. Consumes approximately 70% the power of a conventional OMRON model and operates at a current that is as low as 100mW. The surface mounting terminal model incorporate unique terminal structure with high infrared irradiation efficiency which allows the terminal temperature to rise easily when mounting the IRS, thus ensuring excellent soldering. The G6K series fully sealed signal relay is suitable for office automation machines and amusement equipment. Lightweight of 0.7g contributes to higher speed mounting 0.3A at 125VAC, 1A at 30VDC Rated resistive load 37.5VA/30W Maximum resistive switching capacity 10µA at 10mVDC Minimum permissible load 100mΩ Maximum contact resistance 1000MΩ at 500VDC Minimum insulation resistance 3ms Maximum operating (set) time and release (reset) time 100000 operations Electrical service life Applications Signal Processing, Communications & Networking, Building Automation, Test & Measurement, Security, Industrial, Consumer Electronics

Search Keywords: G6K2FYDC5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6K-2F-Y-DC5
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Box
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 70 °C
Dimension:
10 x 6.5 x 5.2 mm
Termination Style:
Gull Wing
Coil Current:
21.1 mA
Contact Form:
2 Form C

IN STOCK: 2,942

Ships today, if you order in

On Order: 2,000   can ship 12/24/25

Minimum Order: 10

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
10
$3.646
50
$3.296
250
$3.111
500
$3.008
1,000
$2.966
2,500
$2.925
5,000
$2.905
7,500 +
$2.894
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
