G7L-2A-BUBJ-CB-AC100/120 by omron electronics

G7L-2A-BUBJ-CB-AC100/120

Omron Electronics

Power relay ideally suited for high inrush fluid pump control ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G7L-2A-BUB-J-CB-AC100/120 is a 2-pole general-purpose Power Relay with AC coil, G7D series. DPST-NO contact configuration, screw terminals, upper bracket mounting. With test button. High-capacity, high-withstand voltage relay with no contact chattering for momentary voltage drops up to 50% of rated voltage. Miniature size for maximum switching capacity, particularly for inductive loads. Wide-range AC-activated coil that handles 100 to 120VAC or 200 to 240VAC at either 50 or 60 Hz. UL Class B construction standard. Safety design with contact gap of 3mm UL94V-0 Flame resistant Upper bracket mount With test button Applications Industrial, Power Management, Automation & Process Control, Motor Drive & Control

Search Keywords: G7L2ABUBJCBAC100120

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G7L-2A-BUBJ-CB-AC100/120
RoHS:
Yes
HTS:
8536490075
COO:
ID
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Tray
Relay Construction:
Non-Latching
AC Coil Voltage:
100,120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPST-NO
Maximum Current Rating:
25 A
Mounting:
Bracket Mount
Termination Style:
Screw Terminal
Push to Test Button:
Yes
Led Indicator:
No
Operating Temperature:
-25 to 60 °C

IN STOCK: 110

Ships today, if you order in

On Order: 2,000   can ship 12/4/25

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
1
$19.982
20
$15.615
40
$15.450
100
$15.120
260
$14.997
500
$14.904
1,000 +
$14.832
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
