MMPQ2222A by onsemi
onsemi Authorized Reseller

MMPQ2222A

The MMPQ2222A is a quad general-purpose NPN silicon transistor array for amplification and switching applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MMPQ2222A is a quad general-purpose NPN silicon transistor array containing four independent transistors in a single SO-16 package. Each transistor is rated for a collector-emitter voltage of 40 Vdc and a continuous collector current of 500 mAdc. Key performance characteristics include a minimum DC current gain (hFE) of 100 at an IC of 150 mA and a typical current-gain bandwidth product of 350 MHz. The device operates over a wide junction temperature range of -55°C to +150°C. Its integrated quad design is ideal for applications requiring matched transistors, saving board space and improving thermal performance in circuits like differential amplifiers and current mirrors.

Search Keywords: MMPQ2222A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
MMPQ2222A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541210095
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2500

IN STOCK: 14

Ships today, if you order in

Buy all 14 in-stock or the regular minimum order quantity of 25

On Order: 5,000   can ship 4/21/27

Stock lot only: 14

Minimum Order Quantity: 25

Factory Lead-Time 36 Weeks

Price (USD)

Qty
Unit Price
1
$1.5058
25
$1.3689
250
$0.8951
500
$0.8765
1,000
$0.8601
2,500
$0.8518
5,000
$0.8425
7,500
$0.8395
10,000 +
$0.8374
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
