SBAT54SLT1G by onsemi
Image is representational - see mfr. specs

SBAT54SLT1G

onsemi

The SBAT54SLT1G is a dual series Schottky barrier diode designed for high-speed switching, circuit protection, and voltage clamping applications. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SBAT54SLT1G is a dual series Schottky barrier diode intended for high-speed switching, circuit protection, and voltage clamping. This device features an extremely fast switching speed with a maximum reverse recovery time of 5.0 ns and a low forward voltage, typically 0.35 V at a 10 mA forward current, which helps reduce conduction losses. It is rated for a reverse voltage of 30 V and a continuous forward current of up to 200 mA. Housed in a miniature SOT-23 surface-mount package and being AEC-Q101 qualified, it is ideal for space-constrained portable, handheld, and automotive applications.

Search Keywords: SBAT54SLT1G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
SBAT54SLT1G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541100070
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000

IN STOCK: 132,000

Can Ship immediately

Minimum Order Quantity: 3000

Multiple: 3000

Factory Lead-Time 43 Weeks

Price (USD)

Qty
Unit Price
3,000
$0.0252
9,000
$0.0244
27,000
$0.0237
51,000
$0.0232
102,000
$0.0229
150,000
$0.0228
252,000
$0.0228
501,000 +
$0.0227
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes
