1748170000 by weidmuller
Image is representational - see manufacturer specifications
Weidmuller Authorized Distributor

1748170000

Conn Terminal Block SKT 6 POS 3.5mm Crimp ST Panel Mount 10A Box ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1277870000 is a 6-pole, 180° female plug-in PCB connector from the OMNIMATE Signal B2L series, designed for high-density signal connections using a tension-clamp system. It features a 3.50 mm pitch and accepts a wire clamping range from 0.08 mm² to 1.0 mm² (AWG 28-18). The connector is rated for 250V and 10.3A according to IEC standards, and 300V and 10A per UL standards. With an operating temperature range of -50°C to 100°C and a UL 94 V-0 flammability rating, this connector is ideal for reliable field connections of sensor cables in industrial automation and other space-constrained environments.

Search Keywords: 1748170000

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Weidmuller
Part No:
1748170000
Alias/AKA:
1748170000
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
75
Type:
Terminal Block3837
Mounting:
Panel Mount3828
Gender:
SKT3821
Termination Method:
Crimp3836
Pitch:
3.5 mm
Number of Circuits:
33829
Maximum Voltage Rating:
3003826V
Maximum Current Rating:
10 A
Wire Size:
16-28 AWG
Operating Temperature:
-50 to 100 °C
  Possible Replacement options available.  See Alternatives

IN STOCK: 246

Ships today, if you order in

Minimum Order Quantity: 20

Factory Lead-Time 14 Weeks
