AGN20003 by panasonic electronic components

AGN20003

Panasonic Electronic Components

Signal Relay 3VDC 1A DPDT(10.6x5.7x9)mm THT ...

Datasheet
RoHS Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT AGN20003 is a signal relay designed for efficient and reliable switching of electrical signals. With a 3VDC coil voltage, this relay can handle a maximum current of 1A. The DPDT configuration ensures flexibility in connectivity options. The compact dimensions of 10.6x5.7x9mm make it suitable for through-hole mounting on a PCB. Trust in the quality and performance of this PANASONIC EW/AROMAT signal relay for your electronic applications.

Search Keywords: AGN20003

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AGN20003
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
3 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
10.6 x 5.7 x 9 mm
Termination Style:
PC Pin
Coil Current:
46.7 mA
Contact Form:
2 Form C

IN STOCK: 1,400

Can Ship immediately

Minimum Order: 50

Multiple: 50

Factory Lead-Time 14 Weeks

Price (CAD)

Qty
Unit Price
50
$3.992
250
$2.912
500
$2.823
1,000
$2.810
2,500
$2.796
5,000
$2.780
7,500
$2.767
10,000 +
$2.753
