AQS225R2S by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

AQS225R2S

Solid State Relay 50mA 1.5V DC-IN 0.07A 80V AC/DC-OUT 16-Pin SOP Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT part AQS225R2S is a solid state relay with a compact 16-pin SOP (Small Outline Package) design. It features a low input current of 50mA and operates at a low input voltage of 1.5V DC. With an output current of 0.07A and a maximum output voltage of 80V AC/DC, this solid state relay provides efficient and reliable switching performance. The AQS225R2S is an ideal component for applications requiring precise control and protection in various electrical systems. It comes packaged in a tube for convenient storage and handling.

Search Keywords: AQS225R2S

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQS225R2S
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Output Type:
AC,DC
Maximum Output Voltage:
80 V
Maximum Output Current:
0.07 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Surface Mount
Circuit Arrangement:
4 Form A
Dimension:
10.37 x 4.4 x 2.1 mm

IN STOCK: 0

On Order: 2,120   can ship 2/10/27

Minimum Order Quantity: 5

Factory Lead-Time 37 Weeks

Price (USD)

Qty
Unit Price
5
$17.00
10
$15.12
25
$14.32
50
$13.71
100
$13.65
250
$13.62
500 +
$13.58
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes
