AQY212EHA by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

AQY212EHA

Solid State Relay 50mA 1.5V DC-IN 0.55A 60V AC/DC-OUT 4-Pin DIP SMD Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AQY212EHA is a PhotoMOS GE 1 Form A relay designed for low-level analog signal control with reinforced insulation of 5,000 Vrms. It features a 60 V peak AC load voltage rating with a continuous load current of 550 mA (0.55 A) and peak load current of 1.5 A, making it suitable for AC/DC dual-use applications. The device exhibits high sensitivity and low on-resistance characteristics, with a low off-state leakage current of maximum 1 µA, and operates reliably across an ambient temperature range of -40°C to +85°C. The DIP4-pin package with reinforced insulation is ideal for modem, telephone equipment, electricity plant equipment, security equipment, and sensing applications where galvanic isolation and compact form factor are required.

Search Keywords: AQY212EHA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQY212EHA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Output Type:
AC,DC
Maximum Output Voltage:
60 V
Maximum Output Current:
0.55 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Surface Mount
Circuit Arrangement:
1 Form A
Dimension:
4.78 x 6.4 x 2.9 mm
  Different packaging options available.  See Alternatives

IN STOCK: 1,670

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 37 Weeks

Price (USD)

Qty
Unit Price
10
$2.051
50
$1.077
100
$1.045
300
$1.025
500 +
$0.974
