1727049 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1727049

PCB terminal block - nominal current: 13.5 A - rated voltage (III/2): 200 V - nominal cross section: 1.5 mm² - pitch: 3.81 mm - number of positions: 5 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1727049 is a high-quality PCB terminal block that is designed for a wide range of electrical applications. It has a nominal current rating of 13.5 A and a rated voltage of 200 V, making it suitable for use in various power circuits.With a nominal cross-section of 1.5 mm² and a pitch of 3.81 mm, this terminal block provides secure and reliable connections for different types of conductors. It features a screw connection with tension sleeve, ensuring a tight and vibration-resistant connection.The terminal block has 5 positions, allowing for multiple connections in a compact space. It is designed for easy mounting through wave soldering and has a 0° conductor/PCB connection direction.In terms of aesthetics, the terminal block is green in color, which stands out in an electrical setup, making it easy to identify. It also has a linear pinning layout and solder pins with a length of 3.5 mm.Overall, the PHOENIX CONTACT part 1727049 offers a reliable and efficient solution for your PCB connection needs, with its high-current rating, secure connection method, and easy installation process.

Search Keywords: 1727049

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1727049
Alias/AKA:
1727049
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
250
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
3.81 mm
Number of Circuits:
5
Maximum Voltage Rating:
160@IEC,300@UL V
Maximum Current Rating:
13.5 A
Wire Size:
16-26 AWG
Operating Temperature:
N/A

IN STOCK: 487

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
10
$2.94
50
$2.37
250
$2.33
500
$2.32
1,000
$2.31
2,500
$2.30
5,000
$2.29
7,500 +
$2.28
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Accessories

1051993

Marker pen - for manual labeling of unprinted Zack strips - smear-proof and waterproof - l ...

1205037

Screwdriver - slot-headed - VDE insulated - size: 0.4 x 2.5 x 80 mm - 2-component grip - w ...
