AQZ107 by panasonic electronic components
Image is representational - see mfr. specs

AQZ107

Panasonic Electronic Components

The AQZ107 is a DC-type, 1 Form A Power PhotoMOS relay capable of switching a 200 V load at up to 1.3 A. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AQZ107 is a DC-only, 1 Form A Power PhotoMOS solid-state relay housed in a slim SIL4-pin package. It is designed to handle a DC load voltage of up to 200 V with a continuous load current of 1.3 A and a peak load current of 3.0 A. Key features include a high I/O isolation voltage of 2,500 Vrms, a low maximum on-resistance of 0.55 Ω, and a wide operating temperature range from -40°C to +85°C. This relay is suitable for various industrial applications such as measuring instruments and industrial machines, offering reliable, silent, and arc-free switching.

Search Keywords: AQZ107

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQZ107
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Output Type:
DC
Maximum Output Voltage:
200 V
Maximum Output Current:
1.3 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Through Hole
Circuit Arrangement:
1 Form A
Dimension:
21 x 3.5 x 12.5 mm

IN STOCK: 53

Can Ship immediately

On Order: 1,000   can ship 6/17/26

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
25
$5.47
50
$5.37
100
$5.06
250
$5.00
500
$4.96
1,000
$4.93
2,500
$4.86
5,000 +
$4.84
Suppliers Standard Package
