CB1F-R-WM-12V by panasonic electronic components
Image is representational - see mfr. specs

CB1F-R-WM-12V

Panasonic Electronic Components

Relays 12VDC 89.5Ohm 40(NO)/30(NC)A SPDT(30mm 22mm 52mm) Bracket Automotive Relay Automotive ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT CB1F-R-WM-12V is a high-quality automotive relay designed for use in vehicles. This relay operates at 12VDC with a resistance of 89.5Ohm and features a SPDT configuration with 40(NO) and 30(NC) amp switching capabilities. The compact size of 30mm x 22mm x 52mm makes it easy to install in various automotive applications. This relay includes a bracket for secure mounting and is ideal for automotive systems requiring reliable electrical control.

Search Keywords: CB1FRWM12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1F-R-WM-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
40A (NO) / 30A (NC)
Coil Voltage:
12 VDC
Coil Current:
134 mA
Coil Resistance:
89.5 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7 VDC
Must Release Voltage:
4.2 VDC
Operate Time:
15 ms
Seal:
Flux Resistant
Mounting:
Bracket Mount
Termination Style:
0.25 Quick Connect
Dimension:
30 x 22 x 52 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton

IN STOCK: 751

Can Ship immediately

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
50
$4.846
100
$4.634
250
$4.382
500
$4.231
1,000
$4.086
2,500
$4.065
5,000
$4.045
7,500 +
$4.024
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
