DESCRIPTION

JTN1AS-TMP-F-DC15V is a compact economical 30 A relay designed for PCB and TMP mounting applications with high switching capacity. This relay features a 1 Form A contact arrangement with AgSnO2 contact material, delivering a maximum switching power of 8310 VA at 277 V AC and a maximum switching current of 30 A. The coil operates at 15 V DC nominal voltage with a pick-up voltage of 11.25 V DC (maximum) and a drop-out voltage of 1.5 V DC (minimum), with a coil resistance of 281 O and nominal operating power of approximately 800 mW. The relay exhibits excellent mechanical life expectancy of minimum 1×107 cycles and electrical life of minimum 1×105 cycles at 20 A 277 V AC resistive load, with an operate time of maximum 20 ms and release time of maximum 10 ms. This relay is UL/CSA recognized and ideal for automotive, air conditioning, heating and ventilation, and home appliance applications requiring reliable high-capacity switching.
