SP2-L2-DC24V by panasonic electronic components
Image is representational - see mfr. specs

SP2-L2-DC24V

Panasonic Electronic Components

Power Relay 24VDC 10DC/15AAC DPDT(51x25.6x27.65)mm Plug-In ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SP2-L2-DC24V is a 2-Form C, 2-coil latching polarized power relay designed for automation and control applications. It features a compact, slim form factor with an overall height less than half that of comparable HP relays, enabling significant space savings in device designs. The relay incorporates a high-efficiency polarized electromagnetic mechanism with exclusive spring alignment, achieving a minimum operating power of 150 mW for direct transistor or chip controller driving. With a contact arrangement of 2 Form C and a nominal coil voltage of 24V DC, it delivers reliable switching performance rated at 15A/250V AC. The relay demonstrates exceptional reliability through its twin contact design and minimal contact bounce characteristics, with electrical life exceeding 107 operations at 20 cycles per minute. This makes it ideal for industrial automation, control systems, and applications requiring long-term dependable switching performance.

Search Keywords: SP2L2DC24V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
SP2-L2-DC24V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Relay Construction:
Latching Double Coil
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Mounting:
Connector
Termination Style:
0.187Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-50 to 60 °C
Coil Resistance:
1.92 KOhm

IN STOCK: 30

Ships today, if you order in

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
1
$65.82
5
$45.62
20
$39.14
40
$37.04
60
$33.93
100
$33.67
260 +
$33.59
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

SP2-PS

SP Relay Socket

SP2-SF

Relay Socket for Electromechanical Relay

SP-MA

Relay Accessories Base Plate for Power Relay

Show 1 More
