SP2-P-DC24V by panasonic electronic components

SP2-P-DC24V

Panasonic Electronic Components

Power Relay 24VDC 10DC/15AAC DPDT(51x25.6x22)mm THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT SP2-P-DC24V is a power relay designed for various electrical applications. With a coil voltage of 24VDC, this relay has a current rating of 10DC/15AAC. The relay's DPDT (Double-Pole Double-Throw) configuration allows for versatile switching between two independent circuits. Its compact dimensions of 51x25.6x22mm make it easy to integrate into different systems. The relay is designed for Through-Hole Technology (THT) mounting, ensuring secure and stable connections. Suitable for a wide range of industrial, automotive, and home automation projects, the PANASONIC EW/AROMAT SP2-P-DC24V power relay offers reliable performance and durability.

Search Keywords: SP2PDC24V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
SP2-P-DC24V
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-50 to 60 °C
Coil Resistance:
1.92 KOhm

IN STOCK: 0

On Order: 400   can ship 12/3/25

Factory Lead-Time 28 Weeks

Price (CAD)

Qty
Unit Price
1
$97.376
5
$68.296
20
$56.933
40
$53.182
100
$51.299
260
$50.105
500 +
$49.845
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

SP2-PS

SP Relay Socket

SP2-SF

Relay Socket for Electromechanical Relay

SP-MA

Relay Accessories Base Plate for Power Relay

Show 1 More
