PNF10-10R-L

Panduit

Ring Terminal, 12 – 10 AWG, #10 stud size, funnel entry, nylon insulated, standard package. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

Ring Terminal, 12 – 10 AWG, #10 stud size, funnel entry, nylon insulated, standard package.

Product Highlights:

Ring tongue design assures a secure connection in high vibration applications
Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications
Internal barrel serrations assure good wire contact and maximum tensile strength
UL Flammability UL 94V-2/HB, maximum insulation temperature 221°F (105°C)
UL and CSA rated up to 600 V per UL 486
‡UL and CSA approved tooling/product combinations.Note: Wire sizes #26 – #22 AWG, are not UL Listed or CSA Certified.

Potential Applications:

Search Keywords: PNF1010RL

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Panduit

Part No:

PNF10-10R-L

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
