PV14-8LF-C

Name: PV14-8LF-C
Brand: Panduit
SKU: 12213501
Price: 415 USD
Availability: BackOrder

Locking Fork Terminal, vinyl insulated, funnel entry, 18- 14 AWG, #8 stud size, standard package. ...

View Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The PV14-8LF-C Pan-Term® Terminal is a vinyl insulated, locking fork terminal. Brazed seam protects terminal barrel from splitting during the crimp process. Barrel serrations assure good wire contact and maximum tensile strength.

Product Highlights:

Ring tongue design assures a secure connection in high vibration applications
Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications
Internal barrel serrations assure good wire contact and maximum tensile strength
UL Flammability UL 94V-2/HB, maximum insulation temperature 221°F (105°C)
UL and CSA rated up to 600 V per UL 486
‡UL and CSA approved tooling/product combinations.Note: Wire sizes #26 – #22 AWG, are not UL Listed or CSA Certified.

Potential Applications:

Search Keywords: PV148LFC

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Panduit

Part No:

PV14-8LF-C

Alias/AKA:

PV14-8LF-C

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
