0442079 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

0442079

The 0442079 is a single-position, green-yellow ground modular terminal block that utilizes a screw connection method for DIN rail mounting. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 0442079 is a ground modular terminal block designed for secure grounding applications. It features a screw connection that accepts a conductor cross-section from 0.2 mm² to 10 mm² (24-8 AWG). The block is made from polyamide (PA) insulating material with a V0 flammability rating and has a rated surge voltage of 8 kV. With a width of 8.2 mm, it is designed for mounting on NS 35/7,5, NS 35/15, and NS 32 type DIN rails. This component provides a reliable and standards-compliant grounding point in electrical cabinets and industrial systems.

Search Keywords: 0442079

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
0442079
Alias/AKA:
0442079
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Body Orientation:
Straight

IN STOCK: 108

Can Ship immediately

Minimum Order Quantity: 3

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
3
$13.20
25
$12.55
50 +
$11.92
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes

Accessories

NS-35/15-ZN-PERF-2000MM

DIN Rail - 35mmx15mm - Slotted - 2m

ZB-8-CUS

Zack marker strip - can be ordered: Strip - white - labeled according to customer specific ...

UC-TM-8-CUS

Marker for terminal blocks - can be ordered: by sheet - white - labeled according to custo ...

NS-35/15-UNPERF-2000MM

The 1201714 is an unperforated, standard profile DIN rail made of galvanized steel, measur ...

E/UK

End clamp - width: 9.5 mm - height: 35.3 mm - material: PA - length: 50.5 mm - Mounting on ...

UC-TM-8

Connector Accessories Terminal Block Marker Straight Polyamide White

NS-32-UNPERF-2000MM

DIN Rail - 32mmx15mm - Unslotted - Steel 2m

NS-35/15-ZN-UNPERF-2000MM

DIN Rail - 35mmx15mm - Unslotted - Steel 2m

E/UK-1

End clamps - for supporting the ends of double-level and three-level terminal blocks - wid ...

UCT-TM-8

Marker for terminal blocks - Sheet - white - unlabeled - can be labeled with: TOPMARK NEO ...

NS-35/15-CAP

DIN rail end piece - for DIN rail NS 35/15

NS-35/15-WH-PERF-2000MM

Connector Accessories DIN Rail Straight Steel White

NS-32-PERF-2000MM

DIN Rail - 32mmx15mm - Slotted - 2m

ZB-8:UNBEDRUCKT

Zack marker strip - Strip - white - unlabeled - can be labeled with: CMS-P1-PLOTTER - PLOT ...

NS-35/15-PERF-2000MM

DIN Rail - 35mmx15mm - Slotted - 2m

NS-35/15-AL-UNPERF-2000MM

DIN Rail - 35mmx15mm - Unslotted - Aluminum - 2m

ZB-8,QR:FORTL.ZAHLEN

Zack marker strip - Strip - white - labeled - can be labeled with: CMS-P1-PLOTTER - Printe ...

Show 15 More
