0920083

Phoenix Contact

Fuse modular terminal block - without fuse plug - nom. voltage: 500 V - nominal current: 10 A - connection method: Screw connection - cross section: 0.5 mm² - 16 mm² - AWG: 20 - 6 - length: 61 mm - width: 10.2 mm - color: black - mounting: NS 35/7,5 - NS 35/15 - NS 32 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part USIG is a fuse modular terminal block designed for use without a fuse plug. With a nominal voltage of 500 V and nominal current of 10 A, this terminal block features a screw connection method suitable for wire cross sections ranging from 0.5 mm² to 16 mm² (AWG 20-6). Measuring 61 mm in length and 10.2 mm in width, the terminal block comes in a sleek black color and is designed for mounting on NS 35/7.5, NS 35/15, and NS 32 rails.

Search Keywords: 0920083

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
0920083
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Family:
920083
Contact Plating:
N/A
Body Orientation:
N/A
Dimension:
61mm x 10.2mm x 59.1mm
Contact Material:
N/A
Housing Color:
Black
Gender:
F

IN STOCK: 100

Ships today, if you order in

Minimum Order: 2

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
2
$19.569
25
$19.172
50 +
$18.789
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
