1419331

The 1419331 is a shielded, 5-position, A-coded M12 flush-type socket connector designed for rear mounting, pre-assembled with a 2-meter PUR cable. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 1419331 is a 5-position, A-coded M12 flush-type socket connector designed for rear/screw panel mounting via an M16 x 1.5 thread. It comes pre-assembled with a 2-meter, halogen-free PUR cable containing five 0.34 mm² individual wires. This shielded connector is rated for 60 V and 4 A, with a surge voltage rating of 1.5 kV and an insulation resistance of at least 100 MΩ. It provides an IP67 degree of protection when plugged in and is suitable for an operating temperature range of -25 °C to 85 °C, ensuring reliable performance in various industrial applications.

Product Highlights:

Potential Applications:

Search Keywords: 1419331

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

1419331

Alias/AKA:

1419331

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8544429090

COO:

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
