Connector - Universal - 5-position - Plug straight M12 - A-coded - Screw connection - knurl material: Zinc die-cast - nickel-plated - cable gland Pg7 - external cable diameter 4 mm ... 6 mm ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

1663116 is a 5-position, straight plug, universal M12 connector. This A-coded connector is screw connected, which is a proven connection technology for a large selection of different conductors. Contact material is made of Copper Zinc in bright alloy/white bronze finish and knurl material is nickel plated zinc die-cast. The product has Pg7 cable glands, housing diameter of 20mm, length of 60mm, and external cable diameter of 4mm to 6mm. Conductor cross section is 18 to 24AWG.

Product Highlights:

Potential Applications:

Search Keywords: 1663116

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

1663116

RoHS:

Yes

HTS:

8536694020

COO:

ECCN:

EAR99
