1702473

PCB terminal block - nominal current: 6 A - rated voltage (III/2): 160 V - nominal cross section: 0.5 mm² - pitch: 2.5 mm - number of positions: 2 - connection method: Push-in spring connection - mounting: SMD soldering - conductor/PCB connection direction: 0 ° - color: black - Pin layout: Linear pad geometry ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1702473 is a PCB terminal block designed for electronic applications. It has a nominal current of 6 A and a rated voltage of 160 V. The terminal block accepts a nominal cross-section of 0.5 mm² and has a pitch of 2.5 mm with 2 positions available. The connection method is a convenient push-in spring connection, and it is mounted using SMD soldering. The conductor/PCB connection direction is at 0°, and the color of the terminal block is black. With a linear pad geometry for the pin layout, this terminal block is a reliable choice for secure and efficient PCB connections.

Search Keywords: 1702473

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1702473
Alias/AKA:
1702473
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
IN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
770
Type:
PC Terminal Block
Mounting:
Surface Mount
Gender:
N/A
Termination Method:
Solder
Pitch:
2.5 mm
Number of Circuits:
2
Maximum Voltage Rating:
160 V
Maximum Current Rating:
6 A
Wire Size:
20-26 AWG
Operating Temperature:
-40 to 100 °C

IN STOCK: 1,540

Can Ship immediately

On Order: 1,540   can ship 2/18/27

Minimum Order Quantity: 50

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
50
$0.788
250
$0.762
770
$0.750
1,540
$0.746
3,080
$0.744
5,390
$0.742
7,700
$0.740
10,010 +
$0.739
