1702610

Phoenix Contact

PCB terminal block - nominal current: 4 A - rated voltage (III/2): 160 V - nominal cross section: 0.34 mm² - pitch: 2.5 mm - number of positions: 2 - connection method: Displacement connection - mounting: THR soldering - conductor/PCB connection direction: 0 ° - color: black - Pin layout: Zigzag pinning W - Solder pin [P]: 2 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT 1702610 is a PCB terminal block designed for applications requiring a nominal current of 4 A and a rated voltage of up to 160 V. With a nominal cross section of 0.34 mm² and a pitch of 2.5 mm, this terminal block features 2 positions and utilizes a displacement connection method for easy and secure installation. The THR soldering mounting method ensures a reliable connection, while the conductor/PCB connection direction is set at 0°. The terminal block comes in a sleek black color and features a zigzag pinning W pin layout with solder pins measuring 2 mm in length.

Search Keywords: 1702610

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1702610
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
2.5 mm
Number of Circuits:
2
Maximum Voltage Rating:
160 V
Maximum Current Rating:
4 A
Wire Size:
22-26 AWG
Operating Temperature:
N/A

IN STOCK: 500

Ships today, if you order in

Minimum Order: 25

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
25
$1.671
250
$1.392
500
$1.371
1,000
$1.259
2,500
$1.225
5,000
$1.192
7,500
$1.176
10,000 +
$1.158
