1708042

PCB terminal block - nominal current: 8 A - rated voltage (III/2): 200 V - nominal cross section: 1 mm² - pitch: 3.81 mm - number of positions: 4 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1708042 is a compact and reliable PCB terminal block designed for easy and secure connections. With a nominal current of 8 A and a rated voltage of 200 V, this terminal block can reliably handle your electrical needs. The terminal block has a nominal cross section of 1 mm² and a pitch of 3.81 mm, allowing for easy installation on your PCB. Featuring 4 positions, this terminal block offers plenty of room for your connections. The screw connection with tension sleeve ensures a secure and stable connection, and the green color adds a touch of visibility to your circuit. The connection method is designed for wave soldering, making installation quick and efficient.With a conductor/PCB connection direction of 0° and a linear pinning pin layout, this terminal block allows for flexible and hassle-free installation. The solder pin has a length of 3.5 mm, ensuring a secure and reliable connection.Overall, the PHOENIX CONTACT part 1708042 is a high-quality PCB terminal block that offers easy installation, reliable connections, and durability.

Search Keywords: 1708042

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1708042
Alias/AKA:
1708042
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
IN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
3.81 mm
Number of Circuits:
8
Maximum Voltage Rating:
200 V
Maximum Current Rating:
10 A
Wire Size:
16-26 AWG
Operating Temperature:
N/A

IN STOCK: 0

On Order: 300   can ship 12/9/26

Minimum Order Quantity: 5

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
5
$7.27
25
$6.03
50
$5.96
100
$5.91
250
$5.89
500
$5.88
1,000
$5.86
2,500 +
$5.85
