1715747 by phoenix contact

1715747

Phoenix Contact

PCB terminal block - nominal current: 17.5 A - rated voltage (III/2): 400 V - nominal cross section: 1.5 mm² - pitch: 5.08 mm - number of positions: 4 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm. The article can be aligned to create different nos. of positions! ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1715747 is a reliable and high-quality PCB terminal block designed for various applications. It features a nominal current rating of 17.5 A and a rated voltage of 400 V (III/2). With a nominal cross section of 1.5 mm² and a pitch of 5.08 mm, this terminal block ensures secure and efficient electrical connections.The PCB terminal block is equipped with a screw connection with a tension sleeve, ensuring a safe and durable connection. It is suitable for wave soldering mounting and has a conductor/PCB connection direction of 0°. The green color adds a visual element to easily identify and differentiate the terminal block.Featuring a linear pinning pin layout, this terminal block provides flexibility in creating different numbers of positions for your specific requirements. The solder pin has a length of 3.5 mm, enabling a secure and efficient solder connection.Overall, the PHOENIX CONTACT part 1715747 is a reliable and versatile PCB terminal block, designed to meet your electrical connection needs effectively and efficiently.

Search Keywords: 1715747

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1715747
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
5.08 mm
Number of Circuits:
4
Maximum Voltage Rating:
400 V
Maximum Current Rating:
17.5 A
Wire Size:
14-26 AWG
Operating Temperature:
N/A
  Possible Replacement options available.  See Alternatives

IN STOCK: 183

Ships today, if you order in

On Order: 1,000   can ship 1/23/26

Minimum Order: 10

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
10
$2.699
100
$2.245
250
$2.122
500
$2.029
1,000
$1.978
2,500
$1.926
5,000
$1.895
7,500 +
$1.864
