1725698 by phoenix contact
Image is representational - see mfr. specs

1725698

Phoenix Contact

PCB terminal block - nominal current: 6 A - rated voltage (III/2): 160 V - nominal cross section: 0.5 mm² - pitch: 2.54 mm - number of positions: 6 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1725698 is a compact and reliable PCB terminal block suitable for a variety of applications. It features a nominal current of 6 A and a rated voltage of 160 V, making it suitable for low-power electronic circuits. The terminal block has a nominal cross section of 0.5 mm² and a pitch of 2.54 mm, allowing for easy installation and connections. It has 6 positions and utilizes a screw connection with tension sleeve for secure and efficient wiring. The terminal block is designed for wave soldering mounting and has a conductor/PCB connection direction of 0°, making it easy to integrate into your PCB design. The terminal block is color-coded green for quick and easy identification, and it has a linear pinning pin layout for easy and precise connections. The solder pin has a length of 3.5 mm, ensuring a reliable and durable solder joint.

Search Keywords: 1725698

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1725698
Alias/AKA:
1725698, MPT-0-5/-6-2-54
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
GR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
2.54 mm
Number of Circuits:
6
Maximum Voltage Rating:
63 V
Maximum Current Rating:
6 A
Wire Size:
20-26 AWG
Operating Temperature:
N/A

IN STOCK: 505

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
5
$5.10
50
$4.25
100
$4.01
300
$3.79
500
$3.74
1,000
$3.65
2,500
$3.58
5,000 +
$3.53
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

0804853

Marker card - Card - white - labeled - Horizontal: consecutive numbers 1 ... 10 - 11 ... 2 ...

1205202

Micro screwdriver - bladed - size: 0.4 x 2.0 x 60 mm - 2-component grip - with non-slip gr ...
