1745917 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1745917

The 1745917 is a 4-position printed circuit board plug connector with a 3.81 mm pitch and a push-in spring-cage connection. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1745917 is a 4-position, green plug component designed for printed circuit board applications. It is rated for a nominal current of 8 A and a voltage of 160 V (III/2), with a rated surge voltage of 2.5 kV. This connector features a compact 3.81 mm pitch and an ultra-flat design height of just 7.8 mm. The push-in spring-cage connection method allows for fast and user-friendly conductor termination for wires from 24 to 16 AWG. Its design facilitates maximum contact and packing density, making it ideal for a wide range of combinations with MC 1,5 base strips.

Search Keywords: 1745917

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1745917
Alias/AKA:
1745917
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
250
Type:
Spring Cage
Mounting:
Cable Mount
Gender:
SKT
Termination Method:
N/A
Pitch:
3.81 mm
Number of Circuits:
4
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Wire Size:
16-24 AWG
Operating Temperature:
-40 to 100 °C

IN STOCK: 1,373

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 11 Weeks

Price (USD)

Qty
Unit Price
5
$4.61
50
$3.52
100
$3.49
250
$3.45
500
$3.44
1,000
$3.43
2,500
$3.42
5,000 +
$3.41
