1754559 by phoenix contact

1754559

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 8 - pitch: 5 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.5 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1754559 is a high-quality PCB header designed for various electronic applications. With a nominal current of 12 A and a rated voltage of 320 V (III/2), this header ensures reliable and efficient electrical connections. Featuring a nominal cross section of 2.5 mm², this header is capable of handling high power loads. It is equipped with 8 positions and has a pitch of 5 mm, allowing for easy and secure connections. The green color adds a visually pleasing touch to your circuit board.The header is designed for wave soldering mounting, ensuring a sturdy and long-lasting connection. The pin layout is linear, making it suitable for various circuit board designs. The solder pin has a length of 3.5 mm, providing sufficient space for soldering.With a contact surface coated with tin, this header offers excellent conductivity and corrosion resistance. It is a reliable and durable solution for your PCB needs.

Search Keywords: 1754559

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1754559
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
Shrouded Header (2 Sides)
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
5 mm
Number of Contacts:
8
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 0

On Order: 244   can ship 12/24/25

Minimum Order: 10

Factory Lead-Time 5 Weeks

Price (USD)

Qty
Unit Price
10
$2.936
100
$2.451
300
$2.307
500
$2.184
1,000
$2.153
2,500
$2.101
5,000
$2.070
7,500 +
$2.039
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
