1755529 by phoenix contact

1755529

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 3 - pitch: 5 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1755529 is a set of green PCB headers designed with a nominal current of 12 A and a rated voltage of 320 V. These headers have a nominal cross-section of 2.5 mm² and are equipped with 3 positions for secure and reliable connections. With a pitch of 5mm, the headers are ideal for various electronic applications. The contact surface is coated with tin for improved conductivity and durability. The headers are suitable for wave soldering mounting, ensuring quick and efficient installation. The pin layout is linear, offering simple and convenient pinning. Each solder pin has a length of 3.9 mm for easy connection.

Search Keywords: 1755529

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1755529
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5 mm
Number of Contacts:
3
Maximum Voltage Rating:
250@IEC,300@UL V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 2,000

Ships today, if you order in

Manufacturer Stock: 24,726   can ship 12/5/25

Minimum Order: 250

Multiple: 250

Factory Lead-Time 4 Weeks can ship 12/18/25

Price (USD)

Qty
Unit Price
250
$0.747
500
$0.739
1,000
$0.734
2,500
$0.731
5,000
$0.727
7,500
$0.721
10,000
$0.717
15,000 +
$0.714
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

0804183

Marker card - Card - white - labeled - Horizontal: consecutive numbers 1 ... 10 - 11 ... 2 ...

1755477

Connector Accessories Cap Straight Green

1734401

Coding section - inserted into the recess in the header or the inverted plug - red insulat ...
