1757158 by phoenix contact

1757158

Phoenix Contact

PCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 16 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1757158 is a 16-position, green PCB connector with nominal current of 12A and rated voltage (III/2) of 320 V. It fits conductors with cross sections of 12-24 AWG, connected by M3 screw with tension sleeve. Product's dimesions are 18.3mm x 81.28mm x 15mm (lxwxh), and a pitch of 5.08mm.

Search Keywords: 1757158

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1757158
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
16
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A

IN STOCK: 207

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
5
$23.949
25
$21.362
50
$19.846
100
$18.774
250
$18.483
500
$18.038
1,000 +
$17.763
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
