1757404 by phoenix contact

1757404

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 18 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.5 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1757404 is a PCB header with a variety of features and specifications. It has a nominal current of 12 A, making it suitable for various applications. The rated voltage (III/2) is 320 V, providing reliable electrical connections. The nominal cross section is 2.5 mm², ensuring efficient power transmission. With 18 positions, this PCB header offers flexibility in connectivity options. The pitch of 5.08 mm allows for easy installation and connection with other components. The green color gives it a distinctive appearance, making it easily identifiable. The contact surface is coated with tin, ensuring durability and corrosion resistance. Designed for wave soldering, the mounting process is simple and efficient. The pin layout is linear, allowing for organized and efficient connections. With a solder pin length of 3.5 mm, it provides a secure and stable connection. Overall, the PHOENIX CONTACT part 1757404 is a high-quality PCB header that satisfies various electrical requirements.

Search Keywords: 1757404

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1757404
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Shrouded Header (4 Sides)
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
18
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 200

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
5
$15.409
25
$10.576
100
$9.637
250
$9.051
500
$8.960
1,000
$8.914
2,500
$8.882
5,000 +
$8.836
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
