1758377 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1758377

The 1758377 is a 4-position, green plug component for printed-circuit boards, featuring a screw connection with a tension sleeve and a 5.08 mm pitch. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1758377 is a plug component from the MSTB 2,5/..-ST family, designed for creating board-to-wire connections on printed-circuit boards. It provides 4 positions with a standard 5.08 mm pitch and utilizes a reliable screw connection with a tension sleeve for secure wiring. This connector is rated for a nominal current of 12 A and a voltage of 320 V (III/2), with a rated surge voltage of 4 kV. Constructed from green polyamide (PA) insulating material with a V0 flammability rating, it features tin-plated contacts and accepts conductor cross-sections from 24 to 12 AWG. Its robust design and well-defined electrical characteristics make it suitable for a wide range of industrial and commercial electronic applications.

Search Keywords: 1758377

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1758377
Alias/AKA:
1758377
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
PC Terminal Block
Mounting:
N/A
Gender:
F
Termination Method:
N/A
Pitch:
5.08 mm
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A

IN STOCK: 923

Ships today, if you order in

Manufacturer Stock: 1,833   can ship 10/5/26

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks can ship 11/18/26
