1766806 by phoenix contact

1766806

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 630 V - nominal cross section: 2.5 mm² - number of positions: 5 - pitch: 7.62 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1766806 is a high-quality PCB header designed for optimal electrical connections. It features a nominal current of 12 A, a rated voltage of 630 V (III/2), and a nominal cross-section of 2.5 mm². This 5-position header has a pitch of 7.62 mm and comes in a vibrant green color. The contact surface is coated with tin for improved conductivity. The header is suitable for wave soldering mounting and features a linear pinning layout with solder pins measuring 3.9 mm in length. Perfect for a wide range of electronic applications, this PCB header ensures secure and reliable connections.

Search Keywords: 1766806

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1766806
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
7.62 mm
Number of Contacts:
5
Maximum Voltage Rating:
630 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 458

Can Ship immediately

Minimum Order: 10

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
10
$4.931
50
$4.365
250
$3.874
500
$3.660
1,000
$3.614
2,500
$3.522
5,000
$3.461
7,500 +
$3.415
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
