1767012 by phoenix contact

1767012

Phoenix Contact

PCB connector - nominal current: 12 A - rated voltage (III/2): 630 V - nominal cross section: 2.5 mm² - number of positions: 3 - pitch: 7.62 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1767012 is a high-quality PCB connector designed for various electrical applications. It features a screw connection with tension sleeve, ensuring secure and reliable connections. With a nominal current rating of 12 A and a rated voltage of 630 V, this connector is suitable for demanding industrial environments. The connector has 3 positions and a pitch of 7.62 mm, allowing for easy installation and maintenance. It has a nominal cross section of 2.5 mm², accommodating different wire sizes. The color of the connector is green, making it easily distinguishable in wiring assemblies.To ensure excellent conductivity and durability, the contact surface is coated with tin. This coating helps to prevent corrosion and ensures long-lasting performance. Overall, the PHOENIX CONTACT part 1767012 is a reliable and efficient solution for any PCB connection needs.

Search Keywords: 1767012

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1767012
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
7.62 mm
Number of Circuits:
3
Maximum Voltage Rating:
630 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A

IN STOCK: 806

Can Ship immediately

Manufacturer Stock: 2,997   can ship 12/5/25

Minimum Order: 5

Factory Lead-Time 10 Weeks can ship 1/29/26

Price (CAD)

Qty
Unit Price
5
$8.667
25
$7.396
100
$6.769
250
$6.400
500
$6.356
1,000
$6.324
2,500
$6.293
5,000 +
$6.263
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
