1771062 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1771062

PCB terminal block - nominal current: 6 A - rated voltage (III/2): 160 V - nominal cross section: 0.5 mm² - pitch: 2.5 mm - number of positions: 6 - connection method: Push-in spring connection - mounting: SMD soldering - conductor/PCB connection direction: 0 ° - color: black - Pin layout: Linear pad geometry ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT part 1771062 is a compact and efficient PCB terminal block, designed for optimal electrical connections in electronic applications. With a nominal current of 6 A and a rated voltage of 160 V (III/2), this terminal block is suitable for low to medium power circuitry. The terminal block features a Push-in spring connection method for easy and secure wire installation, and a pitch of 2.5 mm with 6 positions for versatile connectivity options. The terminal block is designed for SMD soldering mounting and has a sleek black color. The pin layout follows a linear pad geometry, providing a tidy and organized arrangement for your PCB connections.

Search Keywords: 1771062

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1771062
Alias/AKA:
1771062
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
IN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
770
Type:
PC Terminal Block
Mounting:
Surface Mount
Gender:
N/A
Termination Method:
Solder
Pitch:
2.5 mm
Number of Circuits:
6
Maximum Voltage Rating:
160 V
Maximum Current Rating:
6 A
Wire Size:
20-26 AWG
Operating Temperature:
N/A

IN STOCK: 0

On Order: 2,500   can ship 2/22/27

Minimum Order Quantity: 25

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
25
$1.70
100
$1.44
250
$1.42
770
$1.29
1,540
$1.25
3,080
$1.22
5,390
$1.21
7,700 +
$1.19
Supplier's Standard Package
Log in for special pricing
