1778764 by phoenix contact
Image is representational - see mfr. specs

1778764

Phoenix Contact

The 1778764 is a 2-position, 2.5 mm pitch feed-through PCB header designed for SMD soldering applications. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1778764 is a 2-position feed-through PCB header intended for surface-mount applications. It features a 2.5 mm pitch, tin contact surfaces, and is rated for a nominal current of 6 A and a rated voltage of 160 V (III/2) per EN-VDE standards. Constructed from LCP insulating material with a UL 94 V0 flammability rating, the header includes an anti-rotation pin and solder anchors to enhance mechanical stability on the PCB. Designed for integration into automated SMT soldering processes, it is supplied in tape-on-reel packaging, making it suitable for high-volume manufacturing.

Search Keywords: 1778764

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1778764
Alias/AKA:
1778764, PTSM-0-5/-2-HH-2-5-SMD-R32
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
IN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
600
Type:
Shrouded Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Surface Mount
Pitch:
2.5 mm
Number of Contacts:
2
Maximum Voltage Rating:
160 V
Maximum Current Rating:
6 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 1,000

Can Ship immediately

Minimum Order Quantity: 25

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
25
$0.779
250
$0.698
600
$0.692
1,200
$0.687
3,000
$0.683
5,400
$0.680
7,800
$0.677
10,200 +
$0.673
