1803303 by phoenix contact

1803303

Phoenix Contact

PCB headers - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 5 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.4 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1803303 is a high-quality PCB header designed for optimal performance in electronic applications. With a nominal current rating of 8 A and a rated voltage of 160 V, this header ensures efficient and reliable power transmission. Featuring a nominal cross section of 1.5 mm² and 5 positions, it allows for secure and precise connections. The pitch of 3.81 mm makes it compatible with various board layouts. In an eye-catching green color, this header is easily identifiable. The contact surface is coated with tin for enhanced conductivity and corrosion resistance. Designed for convenient installation, it is suitable for wave soldering mounting. The linear pinning pin layout and solder pin with a diameter of 3.4 mm offer ease of use and robustness in various applications. Overall, the PHOENIX CONTACT part 1803303 is a reliable and versatile choice for any electronic project, delivering excellent performance and long-lasting durability.

Search Keywords: 1803303

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1803303
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
5
Maximum Voltage Rating:
160@IEC,300@UL V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 0

On Order: 245   can ship 1/23/26

Minimum Order: 10

Factory Lead-Time 16 Weeks

Price (CAD)

Qty
Unit Price
10
$3.201
100
$2.664
250
$2.511
500
$2.419
1,000
$2.343
2,500
$2.282
5,000
$2.251
7,500 +
$2.221
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
