1803374 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1803374

PCB headers - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 12 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.4 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PHOENIX CONTACT PCB header part 1803374 is a high-quality electronic component designed for reliable and efficient circuit connections. With a nominal current rating of 8 A and a rated voltage of 160 V, it is capable of handling a wide range of power requirements. The header has 12 positions and a pitch of 3.81 mm, providing ample space for various connections. It is color-coded in green for easy identification and features a tin contact surface for enhanced conductivity. The header is designed for wave soldering mounting method and has a linear pinning layout for easy and secure installation. The solder pin has a length of 3.4 mm, ensuring a strong and durable connection. This PHOENIX CONTACT PCB header is a reliable choice for any electronic project.

Search Keywords: 1803374

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1803374
Alias/AKA:
1803374
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Type:
Shrouded Header (4 Sides)
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
12
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 0

On Order: 382   can ship 11/16/26
On Order: 200   can ship 3/24/27

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
50
$4.59
100
$4.54
250
$4.49
500
$4.48
1,000
$4.47
2,500
$4.46
5,000 +
$4.45
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes

Accessories

1841190

Fiber optics, Pitch: 3.81 mm, Number of positions: 10, Dimension a: 2.3 mm, Color: transpa ...

1734634

Coding profile - is inserted into the slot on the plug or inverted header - red insulating ...

1051993

Marker pen - for manual labeling of unprinted Zack strips - smear-proof and waterproof - l ...

1841174

Conn Fiber Optic M Solder RA Thru-Hole

Show 2 More
